Gabion Mesh Roll
Short Description:
Gabion mesh roll can be double twisted hexagonal woven mesh-or welded gabion mesh.
Gabion mesh roll can be double twisted hexagonal woven mesh-or welded gabion mesh. It has excellent tensile strength, corrosion resistance-and long service life. We can provide different opening diameter gabion mesh according to your needs.
Gabion mesh can be used for rockfall mesh, road mesh-and be made into gabion mattress, gabion basket for garden decorations, river bank, etc.
Optional Material:
1.Galvanized wire:zinc coating can be from 40-280g per square meter.
2.Galfan wire:also called aluminum-zinc coated wire (10% Al)zinc weight can be from 200g-500g per square meter.
3.PVC coated wire:The inner wire is galvanized wire-or galfan wire,and the regular color is gray-and green.
Specification:
Item | Mesh wire (mm) | Selvedge wire(mm) | Lacing wire(mm) |
Galvanized /Galfan Gabion box | 2.4 | 3.0 | 2.2 |
2.7 | 3.4 | 2.2 | |
3.0 | 3.9 | 2.2 | |
PVC coated gabion box | 2.4/3.4 | 3.0/4.0 | 2.2/3.2 |
2.7/3.7 | 3.4/4.4 | 2.2/3.2 | |
3.0/4.0 | 3.9/4.9 | 2.2/3.2 |
Mesh size:
60x80mm ,80x100mm,100x120mm
Roll size:
Width:1-4m, Length :25m,50m,100m
Length ,width can be produced as per customers’ requirement.
|  |
 |  |
The last one： Welded Gabion
The next one： Reno Rattresses
As professional mesh manufacturer with more than 20 years’ experience, Glory specializes in manufacturing all types of gabion and fence including gabion, fence, welded mesh and wire.
